Cocoon Tunnel Standard Series Kits

The Cocoon Standard Series:  7.5m – 40m long  x 2.35m high.

(+ up to 3m each tapered end)

Classic Design with a Regenerative Focus.

The Cocoon Standard Series Caterpillar Tunnels are designed for low to medium height crops with crop rotations and the ability to move the structure both quickly and easily to other crop assets in a timely manner. This is acheived with the Cocoon Standard’s ‘Easy Up – Easy Down’ design and forms part of a regenerative focused management plan.

One of the great features is the purlin strap, not only does it make the tunnel fast to relocate but it also provides a strong bracing extending past the tunnel’s ends using the purlin clasp.

Another great feature is ventilation, Side Curtain Hooks provide an easy solution to lifting your tunnels sides.

As with all of ActiveVista’s Caterpillar Tunnels and Add-on kits we have you covered providing real time phone support for your team and easy to follow guides. Combined with a very low price per square metre footprint and subsidised or free shipping to many major centres*

Everything on a Pallet

• All parts supplied, ready to go. Building is easy with our easy to follow instructions and real time phone support for your build team with minimal tool requirement.

Fast Build and Relocation

• The Cocoon Standard Series Tunnel design can be relocated in as little as 3 hours with two people, regulating your plants and environment when and where you need.

All Season Growth

• Perfect greenhouse design for every season, overwintered crops, shoulder season warmth, summer shade

All Season Management

• Irrigate and apply crop management methods by your schedule, not the climate’s

Easily Upgraded

• The Cocoon Standard Series can be upgraded at any time with our range of Add-on kits including Overhead Irrigation Kits, Shade Kits and more.

Shipping Included*

• Delivery included to freight depots in some major centres in Eastern Australia, including capital cities. We subsidise shipping nationally and to New Zealand. Check out our great shipping options here.

Manuals & Specifications

• 4.35m W,  1.5m Hoop Spacing Kit
• 4.9m x 1.5m Hoop Spacing Kit
• 4.35m W, 1.25m Hoop Spacing
• 4.9m W, 1.25m Hoop Spacing

Tunnel Height:                 2.35m                                               2.75m with Lift Kit

Hoop Steel Thickness:      1.5mm (4.35m width)                   2.0mm (4.9m width)

Tunnel Width:                   4.35m width                                    4.9m width

Hoop Diameter:                32mm out­side diameter

Tunnel Film:                       8.5m wide light diffusing 180um green­house plastic 4‑year rat­ing

Purlin Type:                         25mm flat polypropy­lene strap

Assembly times with more than one person:  3+ hours
